Paint Hand Marker DPM Series
Paint Hand Marker
Paint Hand Maker DPM-5D・DPM-5E
Natural operability is pursued by suppressing the effects of vibration.
■Our proprietary development of a stable chassis minimizes engine vibration
and lateral oscillation, making it easy to pull straight and curved lines.
■Accum chamber provides sharp line edge and excellent surface pattern.
■High work efficiency and easy operation by airless system.
■The use of a high-capacity high-performance pump allows the use of high-viscosity
paints.
■It can be used for paint device for various character by hand gun.
| Item No. | DPM-5D | DPM-5E |
| Dimension | (L)1,100 x (H)1,000 x (W)750 mm | (L)1,100 x (H)1,000 x (W)750 mm |
| Weight | 135kg | 125kg |
| Pump | S-70GE | S-70GE |
| Discharge | 7.3L/min | 7.3L/min |
| Line width | 5-30cm(15cm is stsndard) | 5-30cm(15cm is standard) |
| Bead sprread method | Quantative | Natural |
| Spread volume | 20-30g/m(15cm width) | - |
| Bead spread width | 15・20cm | 15cm |
| Vent pulsation system | Accum chamber | Less vibration hose |
| Engine type | Air 4 cycle | |
| Engine rated output | 1.8kW(2.4ps) / 1,800rpm | |
| Tank capacity | 2.5L | |
 |
 Nozzle・Rotating nozzle for DPM-5D・DPM-E |
hand gun (DPM-5D・DPM-5E) Nozzle15cm(standard) |
||||||||||||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||||||||||||
| ◆Rotating nozzle. This nozzle can instantly clear nozzles by rotating the handle and blowing into the nozzle. ※15cm zozzleis standard. |
||||||||||||||||||||||||||||||||||||||||||||||||
