Heat Liner

• Products Road Marking Machine-TOP

Heat Liner HHL-30A・HHL-20A・HHL-15A

High-speed two rotor gear rolls ensure excellent adhesion. High-speed two rotor gear rolls ensure excellent adhesion. It can install for a current kneader vehicle. ■Can be installed on the front and rear wheel. ■High-speed two rotor gear rolls ensure excellent adhesion and clear finish at slitted edge..　 ■Paint thickness is controlled by freely by a lever. fixed paint thickness, discharge width.

Item No. HHL-30A  HHL-20A  HHL-15A   Dimension  (L)1,570 x (H)625 x (W)600 mm  (L)1,570 x (H)625 x (W)500 mm  (L)1,570 x (H)625 x (W)450 mm  Weight  110kg  100kg  93kg  Line Width  30cm  20cm  15cm  Paint method   2 Rotally Gear Roll  Engine type   Air 4 cycle  Engine rated output 3.3kW(4.5ps)/3,600rpm    Fuel tunk 3L     Trolly  Item No. HHL-DS  Bead spreader   HHL-30A  HHL-20A  HHL-15A  Item No.   9D+AG4890  9D-AG4840XA  9D-AG4790
